2 Functions
250
7SD610 Manual
C53000-G1176-C145-4
2.17.5 Differential Protection Values
2.17.5.1 Measured values of the differential protection
The differential and restraint current values of the differential protection which are
listed in the following table can be called up at the front of the device, read out via the
operating interface using a PC with DIGSI or transferred to a control centre via the
system interface.
623 UL3E= MV U L3-E
624 UL12= MV U L12
625 UL23= MV U L23
626 UL31= MV U L31
627 Uen = MV Uen
631 3U0 = MV 3U0 (zero sequence)
633 Ux = MV Ux (separate VT)
634 U1 = MV U1 (positive sequence)
635 U2 = MV U2 (negative sequence)
641 P = MV P (active power)
642 Q = MV Q (reactive power)
643 PF = MV Power Factor
644 Freq= MV Frequency
645 S = MV S (apparent power)
679 U1co= MV U1co (positive sequence, compounding)
684 U0 = MV U0 (zero sequence)
801 Θ/Θtrip = MV Temperat. rise for warning and trip
802 Θ/ΘtripL1= MV Temperature rise for phase L1
803 Θ/ΘtripL2= MV Temperature rise for phase L2
804 Θ/ΘtripL3= MV Temperature rise for phase L3
7731 Φ IL1L2= MV PHI IL1L2 (local)
7732 Φ IL2L3= MV PHI IL2L3 (local)
7733 Φ IL3L1= MV PHI IL3L1 (local)
7734 Φ UL1L2= MV PHI UL1L2 (local)
7735 Φ UL2L3= MV PHI UL2L3 (local)
7736 Φ UL3L1= MV PHI UL3L1 (local)
7737 Φ UIL1= MV PHI UIL1 (local)
7738 Φ UIL2= MV PHI UIL2 (local)
7739 Φ UIL3= MV PHI UIL3 (local)
No. Information Type of In-
formation
Comments
