Siemens SIPROTEC 7SD610 User Manual

A Appendix
392
7SD610 Manual
C53000-G1176-C145-4
A.8 Information List
Indications for IEC 60 870-5-103 are always reported ON / OFF if they are subject to
general interrogation for IEC 60 870-5-103. If not, they are reported only as ON.
The function type of Differential Protection 7SD610 regarding IEC 60 870-5-103 refers
to as “compatible function type 192” (Differential Protection).
New user-defined indications or such newly allocated to IEC 60 870-5-103 are set to
ON / OFF and subjected to general interrogation if the information type is not a spon-
taneous event („.._Ev“). Further information on indications can be found in detail in
the SIPROTEC 4 System Description, Order No. E50417-H1100-C151.
In columns „Event Log“, „Trip Log“ and „Ground Fault Log“ the following applies:
UPPER CASE NOTATION “ON/OFF”: definitely set, not allocatable
lower case notation “on/off”: preset, allocatable
*: not preset, allocatable
<blank>: neither preset nor allocatable
In column „Marked in Oscill.Record“ the following applies:
UPPER CASE NOTATION “M”: definitely set, not allocatable
lower case notation “m”: preset, allocatable
*: not preset, allocatable
<blank>: neither preset nor allocatable
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
- Test mode (Test mode) Device IntSP ON
OFF
* * LED BO 192 21 1 Yes
- Stop data transmission (DataS-
top)
Device IntSP ON
OFF
* * LED BO 192 20 1 Yes
- Unlock data transmission via BI
(UnlockDT)
Device IntSP *
- Reset LED (Reset LED) Device IntSP ON * * LED BO 192 19 1 No
- Clock Synchronization (Synch-
Clock)
Device IntSP
_Ev
* * * LED BO
- >Back Light on (>Light on) Device SP ON
OFF
*BI
- Hardware Test Mode (HWTest-
Mod)
Device IntSP ON
OFF
**LEDBO
- Disturbance CFC (Distur.CFC) Device OUT on
off
* LED BO
- Breaker OPENED (Brk
OPENED)
Device IntSP * * * LED BO
- Feeder EARTHED
(FdrEARTHED)
Device IntSP * * * LED BO
- Group A (Group A) Change Group IntSP ON
OFF
* * LED BO 192 23 1 Yes
- Group B (Group B) Change Group IntSP ON
OFF
* * LED BO 192 24 1 Yes
