2 Functions
88
7SD610 Manual
C53000-G1176-C145-4
2.5.5 Information List
4112A T I-REF> 0.00 .. 60.00 sec; ∞ 0.00 sec T I-REF> Time Delay
4113A SLOPE 0.00 .. 0.95 0.00 Slope of Charac. I-REF> =
f(I-SUM)
No. Information Type of In-
formation
Comments
5803 >BLOCK REF SP >BLOCK restricted earth fault prot.
5811 REF OFF OUT Restricted earth fault is switched OFF
5812 REF BLOCKED OUT Restricted earth fault is BLOCKED
5813 REF ACTIVE OUT Restricted earth fault is ACTIVE
5816 REF T start OUT Restr. earth flt.: Time delay started
5817 REF picked up OUT Restr. earth flt.: picked up
5821 REF TRIP OUT Restr. earth flt.: TRIP
5826 REF D: VI REF: Value D at trip (without Tdelay)
5827 REF S: VI REF: Value S at trip (without Tdelay)
Addr. Parameter C Setting Options Default Setting Comments
