2.14 Thermal Overload Protection
197
7SD610 Manual
C53000-G1176-C145-4
Calculating the
overtemperature
The thermal replica is calculated individually for each phase. Address 4206 CALC.
METHOD decides whether the highest of the three calculated temperatures (Θ max) or
their arithmetic average (Average Θ) or the temperature calculated from the phase
with maximum current (Θ from Imax) should be decisive for the thermal alarm and
tripping stage.
Since an overload usually occurs in a balanced way, this setting is of minor impor-
tance. If unbalanced overloads are to be expected, however, these options lead to dif-
ferent results.
Averaging should only be used if a rapid thermal equilibrium is possible in the protect-
ed object, e.g. with belted cables. If the three phases are, however, more or less ther-
mally isolated (e.g. single conductor cables or overhead lines), one of the maximum
settings should be chosen at any rate.
2.14.3 Settings
The table indicates region-specific presettings. Column C (configuration) indicates the
corresponding secondary nominal current of the current transformer.
2.14.4 Information List
Addr. Parameter C Setting Options Default Setting Comments
4201 Ther. OVERLOAD OFF
ON
Alarm Only
OFF Thermal overload protec-
tion
4202 K-FACTOR 0.10 .. 4.00 1.10 K-Factor
4203 TIME CONSTANT 1.0 .. 999.9 min 100.0 min Time Constant
4204 Θ ALARM 50 .. 100 % 90 % Thermal Alarm Stage
4205 I ALARM 1A 0.10 .. 4.00 A 1.00 A Current Overload Alarm
Setpoint
5A 0.50 .. 20.00 A 5.00 A
4206 CALC. METHOD Θ max
Average Θ
Θ from Imax
Θ max Method of Acquiring Tem-
perature
No. Information Type of In-
formation
Comments
1503 >BLK ThOverload SP >BLOCK Thermal Overload Protection
1511 Th.Overload OFF OUT Thermal Overload Protection OFF
1512 Th.Overload BLK OUT Thermal Overload Protection BLOCKED
1513 Th.O/L ACTIVE OUT Thermal Overload Protection ACTIVE
1515 Th.O/L I Alarm OUT Th. Overload: Current Alarm (I alarm)
1516 Th.O/L Θ Alarm OUT Th. Overload Alarm: Near Thermal Trip
1517 Th.O/L Pickup OUT Th. Overload Pickup before trip
1521 Th.O/L TRIP OUT Th. Overload TRIP command
