A.7 Settings
391
7SD610 Manual
C53000-G1176-C145-4
4201 Ther. OVERLOAD Therm. Overload OFF
ON
Alarm Only
OFF Thermal overload protection
4202 K-FACTOR Therm. Overload 0.10 .. 4.00 1.10 K-Factor
4203 TIME CONSTANT Therm. Overload 1.0 .. 999.9 min 100.0 min Time Constant
4204 Θ ALARM Therm. Overload 50 .. 100 % 90 % Thermal Alarm Stage
4205 I ALARM Therm. Overload 1A 0.10 .. 4.00 A 1.00 A Current Overload Alarm Setpoint
5A 0.50 .. 20.00 A 5.00 A
4206 CALC. METHOD Therm. Overload Θ max
Average Θ
Θ from Imax
Θ max Method of Acquiring Tempera-
ture
4501 STATE PROT I 1 Prot. Interface ON
OFF
ON State of protection interface 1
4502 CONNEC. 1 OVER Prot. Interface F.optic direct
Com conv 64 kB
Com conv 128 kB
Com conv 512 kB
F.optic direct Connection 1 over
4505A PROT 1 T-DELAY Prot. Interface 0.1 .. 30.0 ms 30.0 ms Prot 1: Maximal permissible
delay time
4506A PROT 1 UNSYM. Prot. Interface 0.000 .. 3.000 ms 0.100 ms Prot 1: Diff. in send and receive
time
4509 T-DATA DISTURB Prot. Interface 0.05 .. 2.00 sec 0.10 sec Time delay for data disturbance
alarm
4510 T-DATAFAIL Prot. Interface 0.0 .. 60.0 sec 6.0 sec Time del for transmission failure
alarm
4511 PI1 SYNCMODE Prot. Interface TEL and GPS
TEL or GPS
GPS SYNC OFF
TEL and GPS PI1 Synchronizationmode
4512 Td ResetRemote Prot. Interface 0.00 .. 300.00 sec; ∞ 0.00 sec Remote signal RESET DELAY
for comm.fail
4513A PROT1 max ERROR Prot. Interface 0.5 .. 20.0 % 1.0 % Prot 1: Maximal permissible error
rate
4515A PI1 BLOCK UNSYM Prot. Interface YES
NO
YES Prot.1: Block. due to unsym.
delay time
4701 ID OF RELAY 1 Diff.-Topo 1 .. 65534 1 Identification number of relay 1
4702 ID OF RELAY 2 Diff.-Topo 1 .. 65534 2 Identification number of relay 2
4710 LOCAL RELAY Diff.-Topo relay 1
relay 2
relay 1 Local relay is
4801 GPS-SYNC. Prot. Interface ON
OFF
OFF GPS synchronization
4803A TD GPS FAILD Prot. Interface 0.5 .. 60.0 sec 2.1 sec Delay time for local GPS-pulse
loss
