2.11 Undervoltage and Overvoltage Protection (optional)
169
7SD610 Manual
C53000-G1176-C145-4
10252 Uph-e>> PU L2 OUT Uph-e>> Pickup L2
10253 Uph-e>> PU L3 OUT Uph-e>> Pickup L3
10255 Uphph> Pickup OUT Uph-ph> Pickup
10256 Uphph>> Pickup OUT Uph-ph>> Pickup
10257 Uphph>(>)PU L12 OUT Uph-ph>(>) Pickup L1-L2
10258 Uphph>(>)PU L23 OUT Uph-ph>(>) Pickup L2-L3
10259 Uphph>(>)PU L31 OUT Uph-ph>(>) Pickup L3-L1
10260 Uphph> TimeOut OUT Uph-ph> TimeOut
10261 Uphph>> TimeOut OUT Uph-ph>> TimeOut
10262 Uphph>(>) TRIP OUT Uph-ph>(>) TRIP command
10263 Uphph> PU L12 OUT Uph-ph> Pickup L1-L2
10264 Uphph> PU L23 OUT Uph-ph> Pickup L2-L3
10265 Uphph> PU L31 OUT Uph-ph> Pickup L3-L1
10266 Uphph>> PU L12 OUT Uph-ph>> Pickup L1-L2
10267 Uphph>> PU L23 OUT Uph-ph>> Pickup L2-L3
10268 Uphph>> PU L31 OUT Uph-ph>> Pickup L3-L1
10270 3U0> Pickup OUT 3U0> Pickup
10271 3U0>> Pickup OUT 3U0>> Pickup
10272 3U0> TimeOut OUT 3U0> TimeOut
10273 3U0>> TimeOut OUT 3U0>> TimeOut
10274 3U0>(>) TRIP OUT 3U0>(>) TRIP command
10280 U1> Pickup OUT U1> Pickup
10281 U1>> Pickup OUT U1>> Pickup
10282 U1> TimeOut OUT U1> TimeOut
10283 U1>> TimeOut OUT U1>> TimeOut
10284 U1>(>) TRIP OUT U1>(>) TRIP command
10290 U2> Pickup OUT U2> Pickup
10291 U2>> Pickup OUT U2>> Pickup
10292 U2> TimeOut OUT U2> TimeOut
10293 U2>> TimeOut OUT U2>> TimeOut
10294 U2>(>) TRIP OUT U2>(>) TRIP command
10300 U1< Pickup OUT U1< Pickup
10301 U1<< Pickup OUT U1<< Pickup
10302 U1< TimeOut OUT U1< TimeOut
10303 U1<< TimeOut OUT U1<< TimeOut
10304 U1<(<) TRIP OUT U1<(<) TRIP command
10310 Uph-e< Pickup OUT Uph-e< Pickup
10311 Uph-e<< Pickup OUT Uph-e<< Pickup
10312 Uph-e<(<) PU L1 OUT Uph-e<(<) Pickup L1
10313 Uph-e<(<) PU L2 OUT Uph-e<(<) Pickup L2
10314 Uph-e<(<) PU L3 OUT Uph-e<(<) Pickup L3
10315 Uph-e< TimeOut OUT Uph-e< TimeOut
10316 Uph-e<< TimeOut OUT Uph-e<< TimeOut
10317 Uph-e<(<) TRIP OUT Uph-e<(<) TRIP command
10318 Uph-e< PU L1 OUT Uph-e< Pickup L1
10319 Uph-e< PU L2 OUT Uph-e< Pickup L2
No. Information Type of In-
formation
Comments
