3 Mounting and Commissioning
304
7SD610 Manual
C53000-G1176-C145-4
The following figure shows a topology example with additional information.
Figure 3-22 Communication topology – Additional representation
Figure 3-23 shows an example of the protection data interface statistics of the device.
The values for the transfer times and the availability are displayed. Both RX and TX
direction of the transmission delay times are displayed, symmetric conditions are
assumed if there is no GPS synchronisation. In this case, the values displayed for the
transfer time are identical.
asynchro-
nous
red The connection cannot be used for protective functions.
unknown grey
Status Colour of the
connection display
Remark
