Siemens SIRIUS 3RH Series - General Data - Control Side and Load Side - Coupling Link 3 RH2924-1 GP11

SIRIUS 3RT2 contactors/contactor assemblies
2.8 Technical data
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
285
2.8.5.5 General data - Control side and load side - coupling link 3RH2924-1GP11
Table 2- 123 General data - Coupling link 3RH2924-1GP11
Type 3RH2924-1GP11
Size Coupling link for mounting on contactors
acc. to IEC 60947/DIN EN 60947
General data
Rated insulation voltage U
i
(pollution degree 3) V 300
Protective separation between coil and contacts
acc. to DIN EN 60947-1, Annex N
V AC Up to 300
Degree of protection to EN 60947-1, Annex C
 Connections
IP20
 Enclosure
IP40
Permissible ambient temperature
 Operation
°C -25 … + 60
 Storage
°C -40 … + 80
Conductor cross-section
 Solid
mm
2
2 x (0.5 to 2.5)
 Finely stranded with end sleeve
mm
2
2 x (0.5 to 1.5)
Connection screws M3
Short-circuit protection
(weld-free fuse protection at I
k
≥1 kA)
fuse links, operating class gL/gG
NH 3NA, DIAZED 5SB, NEOZED 5SE
A 6
Table 2- 124 Control side - Coupling link 3RH2924-1GP11
Type 3RH2924-1GP11
Size Coupling link for mounting on contactors
acc. to IEC 60947/DIN EN 60947
Control side
Rated control supply voltage U
S
V DC 24
Operating range V DC 17 ... 30
Power input at U
S
W 0.5
Rated current consumption mA 20
Release voltage V ≥ 4
Function display Yellow LED
Surge suppressor Varistor
