4.9.8.4 Operating the door-coupling rotary operating mechanism for arduous conditions
Mounting the door-coupling rotary operating mechanisms for arduous conditions
Step Operating instruction
1 / 2 Unscrew the cover from the door-coupling rotary
operating mechanism and remove the cover.


3 / 4 Screw the base of the door-coupling rotary operating
mechanism tight to a level surface and connect to
ground.


