Siemens SIWAREX FTC User Manual

WEIGHING FUNCTIONS AND PARAMETERS
DR Content / Structure Comment Cross-
No. reference
11 Device characteristic curve Loss-in-weight scale
12 PID controller parameter Loss-in-weight scale
13 Material characteristic curve Loss-in-weight scale
14 Current tilt angle Only belt scale (separate manual)
15 Tare input NAWI, Force, Belt scale
5.10
16 Weight simulation value All operating modes
5.11
17 Ext. analog default value All operating modes
5.12
18 Ext. display default value All operating modes
5.13
20 Target_flow_value Loss-in-weight scale
5.14
21 Parameter for batch operation Belt scale (separate manual)
26 Internal state All operating modes
30 Process state 1 NAWI, Force measurement, Belt scale
5.15
31 Process state 2 All operating modes
5.16
32 Process value differential scale Loss-in-weight scale, bulk flow
measurement device
33 Totals Belt scale, loss-in-weight scale, bulk
flow measurement device
5.17
34 ASCII weight value All operating modes
5.18
35 Cryptodata All operating modes
5.19
36 Process values PID-controller Loss-in-weight scale
37 Quality Loss-in-weight scale
40 Log text 1 All operating modes
5.20
41 Log text 2 All operating modes
5.20
42 Log text 3 All operating modes
5.20
43 Log text 4 All operating modes
5.20
44 Last log data All operating modes
5.21
45 String All operating modes
5.22
46 Log ID for requirements through
S7 interface
All operating modes
5.23
47 Log output to S7 interface All operating modes
5.24
120 MMC-trace data All operating modes
5.25
121 RAM-trace data All operating modes
5.25
122 MMC-log data All operating modes
5.27
123 MMC/RAM-Trace-/Log- process
values
All operating modes
5.26
Table 5-1 Data record overview
In the following parameter description, you will find a description of the weighing
functions that are influenced by that parameter.
The parameters of a data record are shown in a table to start with.
This is then followed by the exact parameter description for the parameters of that
data record. After the receipt of new parameters, SIWAREX FTC performs a
SIWAREX FTC
5-31
