Name Type Address Range of Values / Meaning Reference
DE status BYTE DBB026
Current status of the digital inputs (without
pulse input)
5.16.6
Reserve_31_27 BYTE DBB027
Reserve 1
Impedance reference
value
INT
DBW028
Impedance reference value [0.1]
5.16.7
Impedance value INT
DBW030
Impedance actual value [0.1]
5.16.8
32
Table 5-16 Allocation of DR 32
5.16.1 DR 31 – Unfiltered Digital Value
The cu
rrent number of digits from the AD converter is output without being filtered.
5.16.2 DR 31 – Unfiltered Digital Value
The cu
rrent number of digits from the AD converter is output after the filtering.
5.16.3 DR 31 – Operating Error
The cu
rrent existing operating errors (fault) are output as double word.
5.16.4 DR 31 – Date Time
The cu
rrent date and time from the internal clock of the SIWAREX FTC.
5.16.5 DR 31 – Max. Temperature
The maximu
m occurring module temperature (slave pointer).
5.16.6 DR 31 – Status of Digital Inputs
The current si
gnal level on the digital inputs 1...6. The status of the input for the
pulse counter is not indicated.
5.16.7 DR 31 - Impedance Reference Value
The total re
sistance of the load cell(s) which is measured upon commissioning.
Measurement is initiated with an instruction.
5.16.8 DR 31 – Impedance Actual Value
Curre
nt measures total resistance of the load cell(s). Measurement is initiated with
an instruction.
5.17 DR 33 Distribution Memory
Totalizing is performed at the same time for every distribution memory location.
The user can delete a certain location at any time which defines the totalizing
period.
Name Type Address Range of Values / Meaning Reference
Distribution memory 1 REAL DBD000 For saving the total quantity related to WU
5.17.1
5-78 SIWAREX FTC
