Siemens Synco 700 Basic Documentation

146/238
Building Technologies Modular Heating Controller RMH760B CE1P3133en
HVAC Products 9 Heating circuit control 05.02.2007
9.12 Diagnostic choices
Main menu > Heating circuit 1 (or 2 or 3) > Inputs/setpoints
Operating line
Adjustable values / display / remarks
Actual value outside temp
…°C
Simulation outside temperature …°C
Composite outside temp …°C
Attenuated outside temp …°C
Actual value flow temp …°C
Flow temperature setpoint
According to section
9.6 “Mixing valve
control” (load control considered)
Room sensor temp. …°C
Actual value room temp …°C
[Room temperature 1] bus …°C
[Room temperature 2] bus …°C
Room temperature model value …°C
Current room temp setpoint …°C; according to preselection made by the
user, current room operating mode and
interventions
Room setpoint absolute …°C
Room setpoint relative …°C
Actual value return temp …°C
Return temperature max …°C
[Heating circuit pump] overload 0 / 1 (1 = overload)
[Heat circuit pump B] overload 0 / 1 (1 = overload)
Flow signal pump 0 / 1 (1 = pump flow in operation)
Room operating mode 0 / 1 (1 = operating mode according to
contact)
Timer function 0 / 1 (1 = timer function will be activated)
Special day input 0 / 1 (1 = switching program according to
special day is active)
Holiday input 0 / 1 (1 = operation according to holiday
settings)
Main menu > Heating circuit 1 (or 2 or 3) > Outputs
Operating line
Adjustable values / display / remarks
Outside temperature relay Off / On
Mixing valve position 0…100 % (3-position and modulating)
Heating circuit pump Off / On
Heating circuit pump B Off / On
Heating limit relay Off / On
Operating mode relay 1 Off / On
Operating mode relay 2 Off / On
Main menu > Heating circuit 1 (or 2 or 3) > Limitations
Operating line
Adjustable values / display / remarks
Flow temperature max Inactive/ Active
Flow temperature min Inactive/ Active
Flow temperature rise Inactive/ Active
Return temperature max Inactive/ Active
Pulse limitation Inactive/ Active
Inputs / setpoints
Outputs
Limitations
