Siemens Synco 700 Basic Documentation

150/238
Building Technologies Modular Heating Controller RMH760B CE1P3133en
HVAC Products 10 DHW heating 05.02.2007
Plant type Description
3133S57
DHW 3
Storage tank charging with external
heat exchanger and flow control
based on the charging temperature
(controlled via the storage tank tem-
perature).
Options:
• Maintained secondary circuit
• Storage tank sensor at the bottom
• Circulating pump
• Consumer control
• Electric immersion heater
• Return temperature limitation
3133S58
DHW 4
Storage tank charging with external
heat exchanger, primary pump and
mixing valve control based on the
charging temperature or the primary
flow temperature (controlled via the
storage tank temperature).
Options:
• Primary flow sensor
• Maintained secondary circuit
• Storage tank sensor at the bottom
• Circulating pump
• Consumer control
• Electric immersion heater
• Return temperature limitation
3133S59
DHW 5
Storage tank charging with external
heat exchanger and primary pump
(controlled via the storage tank tem-
perature).
Options:
• Primary flow sensor
• Maintained secondary circuit
• Storage tank sensor at the bottom
• Circulating pump
• Consumer control
• Electric immersion heater
3133S60
DHW 6
Direct DHW heating (permanent
release or optional control with flow
switch).
Options:
• Flow switch (recommended)
• Circulating pump
• Consumer control
• Return temperature limitation
If the DHW plant type is undefined (display showing “---“), the function block will not
be activated.
10.2.3 3-position or modulating mixing valve
Mixing valve control can be provided either with a 3-position or DC 0…10 V actuator.
The type of actuator used is to be selected via “Extra configuration”.
