TXP-CLC Course
10
Exercise 6
CAO Function Block
Using the task description and I/O list from chapter 6, assign analog outputs to
proper module, slot, and channels in your YDR diagram
Using the instructions from the previous exercise create all necessary YFR
diagrams for analog outputs
Insert and parameterize your CAO function blocks accordingly.
