Feed-back contact switchgear (RMS)
Name: RMS
Function: Defines whether the ”SAG” feed-back message of the blown fuse in the
switchgear can be detected, and with which type of switch. Additionally it is
determined here whether the TAG-OUT function (SP/BFLO) and operating
modes other than semiautomatic can be used.
Range of values: NO--Cont. / Tag--Out no
NC--Cont. / Tag--Out no
NO--Cont. / Tag--Out yes
NC--Cont. / Tag--Out yes
Basic setting: NO--Cont. / Tag--Out no
Meaning:
Feed-back contact & TAG-OUT active
⇒
RMS
Detection using NC contact No 0
Detection using NO contact No 1
Detection using NC contact Yes 2
Detection using NO contact Yes 3
Default setting: 1
Command output response in case of a fault (VBAF)
Name: VBAF
Function: Defines the response of the command outputs in the event of a fault. If
the parameter is activated the command outputs ALE and ALA will not be
deactivated when the following faults occur: Status discrepancy; Feedback error;
and / or Switchgear faulty. Can only be activated by enabling TAG-OUT via
parameter RMS.
Range of values: Not activated / activated
Basic setting: Not activated.
MAN/AUTO changeover (MAUS)
Name: MAUS
Function: Defines whether the MAN/AUTO button in the operation window is
operable. Can only be activated by enabling TAG-OUT via parameter RMS.
Range of values: Not activated / activated
Basic setting: activated.
TAG--OUT changeover (TOUS)
Name: TOUS
Function: Defines whether the TAG--OUT button in the operation window is
operable. Can only be activated by enabling TAG-OUT via parameter RMS.
Range of values: Not activated / activated
Basic setting: activated.
