Siemens TXP-CLC - DCM Function Block

TXP-CLC Course
11
Exercise 7
DCM Function Block
Using the task description and I/O list from chapter 6, assign DCM inputs and
outputs to proper module, slot, and channels in YDR diagrams
Using the instructions from exercise 1 create all necessary YFR diagrams for
DCMs
Using the instructions from exercise 3 parameterize your DCM function blocks
accordingly
Tie in intermingling logic with DCMs using the following instructions and the task
description in chapter 6
Training Center
