TXP CLC Course
Parameters (set the operation of the block)
Function Selector MOT/SOV/BKR
PBR Command output priority
BAV Command output variant
TUM Maximum under voltage time
TWS Timed sequence re-closure
RWE Feed back travel limit switch on
RWA Feed back travel limit switch off
TVE Time to leave limit position
TGL Running time
WRBHAEA Cb. Er. Bl. N.man/auto on/open
WRBHAAZ Cb. Er. Bl. N.man/auto off/closed
WRBSEA Cb. Er. Bl. Protection on/open
WRBSAZ Cb. Er. Bl. Protection off/closed
WEFSPERR Status discrepancy monitoring locked
WEFNSEA No status discrepancy monitoring on/open
WEFNSAZ No status discrepancy monitoring off/closed
NLZ Overshoot time travel limit
RMS Feed back contact limit SAG
VBAF Cmd. Output in case of failure
MAUS Man/Auto changeover
TOUS TAG-OUT changeover
REJ/MAN Reject to manual
OP_MODE Operation mode
BSGF Behavior on switch gear fault
External
operating
station
Selection of actuator type (FUNCTION)
Name: FUNCTION
Function: Defines the actuator type. This information is used for the labeling of
the OM650 detail window and the command buttons.
Range of values: Motor / Solenoid
Motor
Solenoid
Switch / Breaker
Basic setting: Motor / Solenoid
Training Center
