KKS for the Combustion Turbine
The combustion turbine function codes for turbine systems and for the cabinets
are listed in the following table. In some cases the codes listed represent circuit
diagrams or fault signal identification and not actual equipment.
Turbine Systems and Cabinets
AEA01 138kV distribution system
AFA01 69kV distribution system
BAA00 Grounding switches
BAA10 Generator neutral bus
BAA20 Generator 13.8kV bus
BAB11 Generator neutral point cabinet
BAB35 Generator cubicle, phase L1
BAB36 Generator cubicle, phase L2
BAB37 Generator cubicle, phase L3
BAC01 Generator Circuit Breaker
BAT01 Unit Transformer
BBE00 4.16kV equipment
BBE05 Tie feeder
BBT00 Station service change-over
BBT01 Unit aux transformer
BFE00 480V switch-gear equipment
BFE01 – 08 480V switch-gear cabinets
BFT00 Low voltage transformer equipment, 4.16kV/480V
BFT01 Low voltage transformer equipment, 4.16kV/480V
BJL01 Electrical container service distribution panel
BTA10 220V battery cabinet
BTC11 48V battery cabinet
BTL10 220V battery charger cabinet
BTN11 +24V battery charger
BTN11/12 48V battery charger cabinet
BTN12 -24V battery charger
BRU01 Uninteruptible Power Sypply
BUB00 220V switch-gear equipment
BUB01 – 03 220V switch-gear cabinets
BUN00 48V switch-gear equipment
BUN01 – 02 48V switch-gear cabinets
CHA11 – 13 Generator protection cabinets
CHT11 Metering and synchronization cabinet
CHY01 Service cabinet
CHY10 Auxiliary cabinet
CJ N01 Static frequency converter and excitation cabinet
CKY01 Man Machine Interface Diagrams
