MBP14 Fuel gas vent
MBP15 Pilot gas and load rejection valves
MBP20 Fuel gas hybrid burners
MBP21 Left fuel gas differential, premix, and pilot burners
MBP22 Right fuel gas differential, premix, and pilot burners
MBQ11 Ignition fuel gas system
MBR20 Duct exhaust
MBU10 Water injection flow measurement
MBU20 Water injection system
MBU24 Water injection pumps 1 and 2
MBU27 Water injection filter
MBU28 Water injection signal interface
MBU31 Water injection ESV, EFS, and discharge
MBU32 Water injection control
MBV00 Turbine oil supply system
MBV10 Lube oil tank
MBV21 Main lube oil
MBV25 Lube oil coolers and filters
MBV31 Shaft lift system
MBV41 Turning gear system
MBV50 Oil tank ventilation
MBX00 Combustion turbine trip logic
MBX21 Control oil
MBX23 Reset trip device
MBX41 Combustion turbine trip
MBX51 Hydraulic governor
MBY00 Fire protection
MBY10 Combustion turbine governor, dual channel inputs, mixed
fuel operation, interrupt signals, inspection clock
MKA00 Generator cooling fault logic
MKA01 Generator active & reactive power, generator output,
synchronizing unit
MKA05 Generator anti-condensation heaters
MKA10 Generator temperature supervision
MKA12 Generator auxiliaries
MKA20 Generator slot temperatures
MKA31 Generator protection circuit diagrams (MKA31EZ001)
MKA71 Generator cold air, turbine end
MKA73 Generator cold air, exciter end
MKA76 Generator hot air
MKC01 Excitation transformer
MKD11 Generator bearing exciter end
MKD12 Generator bearing turbine end
MKF01 Generator Cooling
MKY01 Excitation equipment and generator protection
