The following I/O list can be derived from the above task description:
Station Slot Ch KKS Sig. Module Type Description Range Setpoint
00CJF01.DA 1 1 00PAC08CP010 XG51 321-7BH00-0AB0 Main pump filter
differential pressure
N/A >2PSI
00CJF01.DA 1 2 00PAC08CP020 XG51 321-7BH00-0AB0 Aux. Pump filter
differential pressure
N/A >2PSI
00CJF01.DA 1 3 00PAC10AP010 SAG 321-7BH00-0AB0 Main pump switch-
gear fault
N/A N/A
00CJF01.DA 1 4 00PAC10AP020 SAG 321-7BH00-0AB0 Aux. pump switch-
gear fault
N/A N/A
00CJF01.DA 1 5 Spare 321-7BH00-0AB0 N/A N/A
00CJF01.DA 1 6 Spare 321-7BH00-0AB0 N/A N/A
00CJF01.DA 1 7 Spare 321-7BH00-0AB0 N/A N/A
00CJF01.DA 1 8 Spare 321-7BH00-0AB0 N/A N/A
00CJF01.DA 1 9 00PAC10AP010 RMA 321-7BH00-0AB0 Main pump check-
back off
N/A N/A
00CJF01.DA 1 10 00PAC10AP010 RME 321-7BH00-0AB0 Main pump check-
back on
N/A N/A
00CJF01.DA 1 11 00PAC10AP020 RMA 321-7BH00-0AB0 Aux. pump check-
back off
N/A N/A
00CJF01.DA 1 12 00PAC10AP020 RME 321-7BH00-0AB0 Aux. pump check-
back on
N/A N/A
00CJF01.DA 1 13 Spare 321-7BH00-0AB0 N/A N/A
00CJF01.DA 1 14 Spare 321-7BH00-0AB0 N/A N/A
00CJF01.DA 1 15 Spare 321-7BH00-0AB0 N/A N/A
00CJF01.DA 1 16 Spare 321-7BH00-0AB0 N/A N/A
00CJF01.DA 2 1 00PAC10AP010 ALA 322-1BH01-0AA0 Main pump command
off
N/A N/A
00CJF01.DA 2 2 00PAC10AP010 ALE 322-1BH01-0AA0 Main pump command
on
N/A N/A
00CJF01.DA 2 3 00PAC10AP020 ALA 322-1BH01-0AA0 Aux. pump command
off
N/A N/A
00CJF01.DA 2 4 00PAC10AP020 ALE 322-1BH01-0AA0 Aux. pump command
on
N/A N/A
00CJF01.DA 2 5 Spare 322-1BH01-0AA0 N/A N/A
00CJF01.DA 2 6 Spare 322-1BH01-0AA0 N/A N/A
00CJF01.DA 2 7 Spare 322-1BH01-0AA0 N/A N/A
00CJF01.DA 2 8 Spare 322-1BH01-0AA0 N/A N/A
00CJF01.DA 2 9 00PAC30AA030 ALE 322-1BH01-0AA0 Emergency Stop
Valve
N/A N/A
00CJF01.DA 2 10 00PAC10AA010 ZV01 322-1BH01-0AA0 Main pump check
valve
N/A N/A
00CJF01.DA 2 11 00PAC10AA020 ZV01 322-1BH01-0AA0 Aux pump check
valve
N/A N/A
