Functional Description
AP10S
Date: 04.09.2017 Art. No. 87826 Mod. status 269/17 Page 12 of 48
4.2 Battery buffering
The battery makes possible the detection of currentless displacement. Battery life is approx. 5
years depending on the duration of battery operation (including storage) and frequency of
currentless adjustments. Battery voltage is checked at intervals of approx. 5 min. If battery
voltage drops below a specified value, the battery symbol will blink on the display. If
the battery voltage continues to drop, will be displayed permanently. The battery
should be replaced within approx. three months after the first appearance of the battery
symbol. The battery can be replaced by the SIKO distribution partners or at the SIKO main
factory. For battery replacement it is mandatory to follow the instructions of the installation
instructions.
Status word:
The charge status of the battery is signified in the status word. Bit 11 is set when the
charging voltage is critical and an error is signified with the additional bit 7 set when the
battery is empty.
4.3 Parameterization of the position indicator
The position indicator can be fully parameterized via the bus interface. You can configure
manually via keyboard the most significant bus parameters (node address, baud rate, protocol,
bus timeout and reponse delay time).
4.3.1 Manual parameterization
4.3.1.1 Starting parameterization
After applying supply voltage and completion of initialization, the position indicator is on the
uppermost level of the menu structure (default/Factory settings).
By actuating the key, the set node address and baud rate is displayed. Parameterization
starts if it is actuated for the duration of the enable time (see parameter 04h: Keys enable
time: Configuration start delay and 3Dh: Key function enable3: Configuration enable via
keyboard).
4.3.1.2 Value input
Enter values via the key and the key. Confirm values entered by pressing the key.
- decimal place selection key
- value input key
