Siko AP10S - 0 Ch: Direction Indicators (CW, CCW); 0 Dh: Display Orientation; 0 Eh: Configuration Programming Mode

Communication via SIKONETZ 5
AP10S Date: 04.09.2017 Art. No. 87826 Mod. status 269/17 Page 30 of 48
6.9.13 0Ch: Direction indicators (CW, CCW)
The display of the direction arrows is set via parameter 0Ch.
Parameter address
0Ch
Description
Representation of the direction indicators
Access
rw
EEPROM
yes
Programming mode
yes
Data type
UNSIGNED 8
Default
0
Data content
0 = On
1 = inverted
2 = Off
6.9.14 0Dh: Display orientation
Display orientation can be set via parameter 0Dh.
Parameter address
0Dh
Description
Display orientation
Access
rw
EEPROM
yes
Programming mode
yes
Data type
UNSIGNED 8
Default
0
Data content
0 = 0°
1 = 180° rotated
6.9.15 0Eh: Configuration programming mode
Basic settings of programming interlock (see chapter 6.7.2: Programming interlock).
Parameter address
0Eh
Description
Configuration programming mode
Access
rw
EEPROM
yes
Programming mode
yes
Data type
UNSIGNED 8
Default
0
Data content
0 = no active programming interlock
1 = active programming interlock
