Siko AP10S - 1 Fh: Calibration Value

Communication via SIKONETZ 5
AP10S Date: 04.09.2017 Art. No. 87826 Mod. status 269/17 Page 32 of 48
Parameter address
1Ch
Description
Number of measurement steps per revolution (GS04)
Access
rw
EEPROM
yes
Programming mode
yes
Data type
UNSIGNED 16
Default
720
Data content
1 … 65535
6.9.18 1Eh: Offset value
The offset value is determined via parameter 1Eh.
Parameter address
1Eh
Description
Offset enables the shifting of a scaled value range. The offset value
is added to the position value in the encoder. Both positive and
negative values are allowed.
Position value = measured value + calibration value + offset value
Access
rw
EEPROM
yes
Programming mode
yes
Data type
SIGNED 16
Default
0
Data content
-29999 … 29999
6.9.19 1Fh: Calibration value
Via parameter 1Fh, the encoder's position value can be set to a calibration value when
calibrating.
To enable the execution of calibration, the "Calibration" system command must be executed
(see chapter 4.6.2: Calibration).
Parameter address
1Fh
Description
calibration value (position value = measured value + calibration
value + offset value)
Access
rw
EEPROM
yes
Programming mode
yes
Data type
SIGNED 32
Default
0
Data content
-999999 … 999999
