Siko AP10S - 3 Fh: Display Factor

Communication via SIKONETZ 5
AP10S Date: 04.09.2017 Art. No. 87826 Mod. status 269/17 Page 39 of 48
6.9.37 3Fh: Display factor
If a display factor> 0 is set, all values on the display are indicated in inch.
It should be noted that the transmission values from and to the interface are present in the
metric system (depending on resolution and ADI). The control delivers target, calibration, and
offset values as well as loop length and target window metrically as well. Device-internal
position monitoring is metrical. Therefore, the superordinate control can only function in the
metric system. The values for position, setpoint and the differential value if applicable are
calculated by means of the following formula (for position value):
Display value = position value x calculation factor
Calculation factor =
1
0.254
x 10
4-Display factor
9 different calculation factors can be set (see Table 17). The number of decimal places is
selected via parameter 0Ah: Decimal places.
Display
factor
Calculation
factor
Meaning
Examples of indication (APU = 400)
Position after 1 revolution = 400
0
1
Metric indication after APU
and ADI
400
1
10
3
0.254
Imperial indication (inch)
1574803
2
10
2
0.254
157480
3
10
1
0.254
15748
4
10
0
0.254
1575
5
10
-1
0.254
158
6
10
-2
0.254
16
7
10
-3
0.254
2
8
10
-4
0.254
0
Table 17: Value table of display factor
Parameter address
3Fh
Description
Display factor
Access
rw
EEPROM
yes
Programming mode
yes
Data type
UNSIGNED 8
Default
0
Data content
0 … 8
