Siko AP10S - C5 H: ADC Values of the Sensor; Cah: Bus Protocol; Cfh: Period Counter

Communication via SIKONETZ 5
AP10S Date: 04.09.2017 Art. No. 87826 Mod. status 269/17 Page 44 of 48
6.9.49 C5h: ADC values of the sensor
The current ADC values of the sensor can be retrieved via parameter C5h.
Parameter address
C5h
Description
ADC values of the sensor
Access
ro
EEPROM
no
Programming mode
no
Data type
UNSIGNED 32
Default
0
Data content
Byte 0
Data content
Byte 0
Data content
ADC_SIN
6.9.50 CAh: Bus protocol
Changes become active only after restart of the device.
Parameter address
CAh
Description
Protocol of the RS485 interface
Access
rw
EEPROM
yes
Programming mode
yes
Data type
UNSIGNED 8
Default
0
Data content
0 = SIKONETZ5
1 = Service protocol
6.9.51 CFh: Period counter
The current values of the period counter can be retrieved via parameter CFh.
Parameter address
CFh
Description
values of the period counter
Access
ro
EEPROM
no
Programming mode
no
Data type
UNSIGNED 32
Default
0
Data content
Byte 0
Byte 1
Byte 2
Byte 3
Quadrant
Period counter
