Siko AP10S - Control Word; Status Word

Communication via SIKONETZ 5
AP10S Date: 04.09.2017 Art. No. 87826 Mod. status 269/17 Page 20 of 48
6.3.4 Control word
The control word consists of 16 bits.
Control word
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
MSB High Byte
Low Byte LSB
The following table lists the designations of the individual bits of the control word and their
meanings.
Bit
Meaning
Value = 0
Value = 1
0
reserved
ever 0
-
1
reserved
ever 0
-
2
Validity of set point1
invalid
valid
3
Display range
standard
extended
4
Acknowledgment target window1 static
not acknowledged
acknowledged
5
Error
not acknowledged
acknowledged
6
With "Display" operating mode:
Acknowledgement of set point2
not acknowledged
acknowledged
7
With "Display" operating mode:
Data identifier
number
ASCII
8
reserved
ever 0
-
9
Validity of set point2
invalid
valid
10
With "Display" operating mode:
Acknowledgement of set point1
not acknowledged
acknowledged
11
LED1 green left
Off
On
12
LED3 green right
Off
On
13
LED4 red right
Off
On
14
LED2 red left
Off
On
15
LED blinking
Off
On
Table 12: Control word
6.3.5 Status word
The status word indicates the current status of AP10S. It consists of 16 bits.
Status word
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
MSB High Byte
Low Byte LSB
The following table lists the designations of the individual bits of the status word and their
meanings.
Bit
Meaning
Value = 0
Value = 1
0
Direction indication CW
Off
On
1
Direction indication CCW
Off
On
2
Validity set point1
invalid
valid
