Absolute position:
Linear absolute position values are displayed.
Differential value display:
With factory setting: Differential value = actual position - set point2
Modulo display:
Position values ranging from 0° to 360° are displayed.
Using the parameter 0Ah: Decimal places the resolution and the modulo point of the
displayed values are set.
Decimal places
Display resolution
Value range
0
1°
0°…360°
1
1/10°
0.0°…360.0°
2
1/100°
0.00°…360.00°
3
1/1000°
0.000°…360.000°
4
1/10000°
0.0000°…360.0000°
Table 2: Modulo display
Alpha-numeric display:
Both rows can be written freely. Set point1 is received via the SIKONETZ5 parameter FBh "set
point1", set point2 via parameter FFh "set point2". The data identifier must be correctly set in
the relevant control word. The data identifier differentiates whether the data is interpreted
and displayed as figures or alpha-numeric characters (ASCII) (see chapter 6.3.4: Control
word).
4.1.1 Position-bound operating modes
4.1.1.1 Positioning
(see chapter 4.1.1.2: Loop positioning)
Arrows: (see parameter 0Ch: Direction indicators (CW, CCW))
Arrows are displayed to support the user with positioning as long as the current actual
position value is outside (see parameter 20h: Target window1 (near field)) target window1.
The direction of the arrow indicates the direction of shaft rotation in order to arrive at the set
point.
LED-Anzeige: (siehe z. B. Parameter 09h: LED1 (green left))
With factory setting, the LED glows green as long as the actual position is within the
programmed window1. When leaving target window1, the LED glows red. The sensor must be
adjusted in the direction of the glowing LED in order to arrive at the set point2. The red
glowing LED on the right means: clockwise (cw) rotation required. Red glowing LED on the
left: counter-clockwise (ccw) rotation required.
