Siko AP10S - A8 H: Programming Mode; Aah: Freeze Actual Value; C3 H: Start Sensor Alignment

Communication via SIKONETZ 5
AP10S Date: 04.09.2017 Art. No. 87826 Mod. status 269/17 Page 43 of 48
6.9.46 A8h: Programming mode
Programming interlock (see chapter 6.7.2: Programming interlock).
Parameter address
A8h
Description
Programming mode
Access
wo
EEPROM
yes
Programming mode
yes
Data type
UNSIGNED 8
Default
0
Data content
0 = parameter programming disabled
1 = parameter programming enabled
6.9.47 AAh: Freeze actual value
The actual position value can be freezed via this parameter. So, synchronized recording of all
position values in the unit can be generated. The status word signifies whether the position
value treansmitted is updated or freezed (see chapter 6.3.5: Status word). Updating of the
position value will be reenabled with the next readout operation.
Parameter address
AAh
Description
The current actual position value is cached (freezed) until the next
readout operation of the actual position.
Access
wo
EEPROM
no
Programming mode
no
Data type
UNSIGNED 8
Default
0
Data content
1 = freeze actual position
6.9.48 C3h: Start sensor alignment
Alignment can be started via parameter C3h (see chapter 4.6.1: Alignment travel).
Parameter address
C3h
Description
Start sensor alignment
Access
wo
EEPROM
no
Programming mode
no
Data type
UNSIGNED 8
Default
0
Data content
1 = Start sensor alignment
