6.9.58 FEh: Position value
The current position value of the device is output under FEh.
Parameter address
FEh
Description
Actual position (see chapter 4.1: Operating modes)
Access
ro
EEPROM
no
Programming mode
no
Data type
SIGNED 32
Default
-
Data content
MS500H: -65536000 … 65536000
GS04: -5242880 … 5242880
Position value = measured value + calibration value + offset value
6.9.59 FFh: Set point2
The current set point2 can be written and read via address FFh.
Parameter address
FFh
Description
Set point2
Access
rw
EEPROM
no
Programming mode
no
Data type
SIGNED / UNSIGNED 32 (depending on the operating mode)
Default
-
Data content
0h … FFFFFFFFh
7 Communication via Service Standard Protocol
7.1 General
The service protocol enables the control of the position indicator via ASCII commands. No
additional devices must be connected to the RS485 interface since this protocol is not bus-
compatible.
An ASCII terminal sends a letter and additional parameters if required (ASCII).
Subsequently, the position indicator sends a reply with a concluding <CR>.
Available baud rates: 19.2 kBit / 57.6 kBit (factory setting) / 115.2 kBit
Additional settings: No parity, 8 data bits, 1 stop bit, no handshake
