6.9.20 20h: Target window1 (near field)
The parameter 20h indicates the window within which the set point is considered reached
(see chapter 4.1.1.1: Positioning).
Parameter address
20h
Description
The set point is reached when the actual value is within the target
window.
Access
rw
EEPROM
yes
Programming mode
yes
Data type
UNSIGNED 16
Default
5
Data content
0 … 9999
6.9.21 21h: Positioning type (loop type)
The positioning type, loop type is indicated via parameter 21h, thereby selecting the direction
from which the set point shall be approached (see chapter 4.1.1.2: Loop positioning).
Parameter address
21h
Description
Set point is approached in this direction.
Access
rw
EEPROM
yes
Programming mode
yes
Data type
UNSIGNED 8
Default
0
Data content
0: no loop
1: loop +
2: loop -
6.9.22 22h: Loop length
Parameter 22h specifies the loop length by which the set point shall be moved over with loop
travel (see chapter 4.1.1.2: Loop positioning).
Parameter address
22h
Description
loop length
Access
rw
EEPROM
yes
Programming mode
yes
Data type
UNSIGNED 16
Default
0
Data content
0 … 9999
