Siko AP10S - 80 H: Number of Errors; 81 H until 8 Ah: Errors; 96 H: Input Errors

Communication via SIKONETZ 5
AP10S Date: 04.09.2017 Art. No. 87826 Mod. status 269/17 Page 41 of 48
6.9.41 80h: Number of errors
See chapter 4.5: Warnings / Errors.
Parameter address
80h
Description
Number of errors recorded
Access
ro
EEPROM
yes
Programming mode
no
Data type
UNSIGNED 8
Default
0
Data content
0 … 10
6.9.42 81h until 8Ah: Errors
See chapter 4.5: Warnings / Errors. The oldest error is found under parameter address 81h, the
most recent error is found under the highest address.
Parameter address
81h until 8Ah
Description
error
Access
ro
EEPROM
yes
Programming mode
no
Data type
UNSIGNED 16
Default
0
Data content
see chapter 4.5.2: Errors
6.9.43 96h: Input errors
Output of a list (10 entries) of input errors (see chapter 6.5.1: SIKONETZ5 error codes).
The list is deleted with initialization of the device at program start (reset or power-on).
The error number must be transferred in data byte 3 of the telegram.
Data byte 3 with the request = 0  number of errors occurring is reported.
Data byte 3 with the request = 1  error number 1 (latest error) is reported.
Example:
Telegram structure of master: latest error (= no. 1) shall be read:
Command
ID
Parameter
ZSW
Error number
CS
00h
1Fh
96h
XX
YY
01h
00h
00h
00h
NNh
Telegram structure of slave: latest error (1) is output:
Command
ID
Parameter
ZSW
Error number
Error code
CS
00h
1Fh
96h
XX
YY
01h
00h
00h
83h
NNh
