Siko AP10S - 31 H: Target Window2 (Extended); 32 H: Target Window2 Visualization; 33 H: Application of the Display Divisor (ADI Application)

Communication via SIKONETZ 5
AP10S Date: 04.09.2017 Art. No. 87826 Mod. status 269/17 Page 35 of 48
6.9.25 31h: Target window2 (extended)
Via parameter 31h, the size of target window2 can be set (see chapter 4.1.1.1: Positioning
and parameter 32h: Target window2 visualization).
Parameter address
31h
Description
Extended target window to facilitate positioning at fast travel speed.
Access
rw
EEPROM
yes
Programming mode
yes
Data type
UNSIGNED 16
Default
0
Data content
0 … 9999
6.9.26 32h: Target window2 visualization
Target window2 visualization can be set via parameter 32h (see chapter 4.1.1.1: Positioning
and parameter 31h: Target window2 (extended)).
Parameter address
32h
Description
target window2 visualization
Access
rw
EEPROM
yes
Programming mode
yes
Data type
UNSIGNED 8
Default
0
Data content
0 = Off
1 = On
6.9.27 33h: Application of the display divisor (ADI application)
The ADI application can be set via parameter 33h.
Parameter address
33h
Description
ADI application
Access
rw
EEPROM
yes
Programming mode
yes
Data type
UNSIGNED 8
Default
0
Data content
0: on all values
1: only on display. Values transferred via the interface are not offset
against the ADI.
