Overview of parameters
AP10S Date: 04.09.2017 Art. No. 87826 Mod. status 269/17 Page 17 of 48
Name
Description
see
page
0Bh: Display divisor (ADI)
ADI display divisor
29
0Ch: Direction indicators (CW, CCW)
Visualization of direction indicators
30
0Dh: Display orientation
Display orientation
30
0Eh: Configuration programming
mode
Basic setting of programming interlock
30
1Bh: Counting direction
Counting direction
31
1Ch: Resolution or measurement
steps per revolution
Resolution of the measuring system
31
1Eh: Offset value
Offset value
32
1Fh: Calibration value
Calibration value
32
20h: Target window1 (near field)
The set point has been reached when the
actual value is within the target window1
33
21h: Positioning type (loop type)
Travel towards set point in this direction
33
22h: Loop length
Loop length
33
28h: Operating mode
Operating mode
34
30h: Display in the 2
nd
row
Controls the display of the 2
nd
row of the
display
34
31h: Target window2 (extended)
Extended target window for easier positioning
35
32h: Target window2 visualization
Visualization of target window2
35
33h: Application of the display
divisor (ADI application)
ADI application
35
34h: Formation of the differential
value
Formation of the differential value
36
35h: Key function enable2:
Incremental measurement enable
Incremental measurement enable
36
38h: Sensor type
Selection of the sensor type
36
39h: LED4 (red right)
LED red right (LED4)
37
3Ah: LCD backlight flashing
Flashing LCD backlight
37
3Bh: LCD backlight white
LCD backlight white
37
3Ch: LCD backlight red
LCD backlight red
38
3Dh: Key function enable3:
Configuration enable via keyboard
Configuration enable
38
3Eh: Acknowledgement settings
Acknowledgment settings (alpha-numeric
display)
38
3Fh: Display factor
Display factor (inch indication)
39
63h: Battery voltage
Battery state of charge
39
65h: Device identification
SIKONETZ5 device identification (AP10S = 9)
40
67h: Software version
Software version
40
80h: Number of errors
Number of error incidents
41
81h until 8Ah: Errors
Error list
41
96h: Input errors
Input error list
41
A0h: System commands
Various system commands
42
A7h: Calibration
Starting calibration
42
