D-1
This appendix contains instructions on how to use the Earth Fault Search feature of the
4100ES-S1 diagnostics menus.
Earth Fault Search is a diagnostic search of external field wiring that assists in locating
circuits with earth faults. An earth fault occurs when an electrical circuit is shorted to
ground. Although most circuits operate with a single earth fault, multiple earth faults can
disable communications. Because of this, earth faults must be located and repaired.
Earth Fault Search is conducted by the 4100ES-S1. The diagnostic may be activated using
either the front panel interface or the Computer Port Protocol via a service port.
The 4100ES-S1 supports two types of Earth Fault Searches:
Location Search. Searches all circuits at a location, such as the main panel.
IDNet Channel Search. Selectively enables channel isolators and repeaters to
detect which segment of the channel wiring has a fault.
Appendix D
Earth Fault Detection
Overview
