Simplex 4100ES-S1 User Manual

F-1
This appendix describes the following:
 Devices that have been approved as compatible devices for use with the 4100ES-S1.
 Devices approved for use with the IDNet and shows the number allowed per loop.
Refer to the page number listed in this table for information on a specific topic.
Topic
See Page #
List of Approved Devices
F-1
Compatible Detectors, IDNET
F-4
Compatible Addressable Field Devices, IDNet
F-5
Simplex Range - Conventional Detectors
4098-9413 Heat detector Type A
4098-9414 Heat detector Type B
4098-9415 Heat detector Type C
4098-9416 Heat detector Type D
2098-9201 Photoelectric smoke detector
2098-9576 Ionisation smoke detector
Detector Type
4100-5001/2/4
8 Zone Module
2190-9156
Monitor ZAM
4090-9101
Monitor ZAM
4098-9601EA Photoelectric *
30
20
20
4098-9603EA Ionisation *
30
20
20
4098-9618EA Heat Type A *
30
20
20
4098-9619EA Heat Type B *
30
20
20
4098-9621EA Heat Type D *
30
20
20
* Remote indicator output cannot be wired in common with Tyco 614 series
or the Minerva M614 series (and most other Tyco/Olsen) detectors.
Tyco Range - Conventional Detectors
Detector Type
4100-5001/2/4
8 Zone Module
2190-9156
Monitor ZAM
4090-9101
Monitor ZAM
614CH
CO/Heat Detector
37
25
25
614I
Ionisation Detector
40
29
29
614P
Photoelectric Detector
28
19
19
614T
Heat Detectors -
Type A, B, C, D
30
20
20
T614
Mk2
Heat Detectors –
Type A, B, C, D
30
20
20
Continued on next page
Appendix F
Compatible Actuating Devices
Introduction
In this Chapter
List of Approved Devices
