Installing Other Modules
Detailed installation instructions for these modules can be found in these instruction
documents. A copy of the appropriate document is supplied in the kit with each module.
Table 2-4. Module Installation Documents for 4100ES-S1
IDNET module provides an additional IDNET loop,
with up to 250 devices.
This is a PDI card.
IDNET+ module provides 1, 2, 3 or 4 additional
IDNET loops with independent fault isolation. The
total number of devices on these loops can be up to
246.
This is a PDI card.
8 point relay module with 8 input points as well.
Relay outputs are each a single changeover contact
rated at 3A at 30V.
This is a legacy card.
4 point relay module with 4 input points as well.
Relay outputs are each a pair of changeover contacts
rated at 2A at 30V.
This is a PDI card.
8 point relay module. Relay outputs are each a pair
of changeover contacts rated at 3A at 30V. There are
no feedback inputs.
This is a PDI card.
8 zone module providing 8 conventional detector
circuit interfaces.
This is a legacy card.
Dual RS-232 serial interface, providing two
independent serial ports for connection printers,
modems, or other 3
rd
party equipment.
This is a legacy card.
VESDA High Level Interface. This is a dual serial
interface customized to connect to a VESDA and
communicate compatible status and control
messages.
This is a legacy card.
24 point Graphic I/O module provides 24
configurable inputs or outputs for direct connection,
e.g., zone displays.
This is a legacy card.
24 point Graphic I/O module provides 24
configurable inputs or outputs with relay isolation,
e.g., fan controls, BMS interfaces.
This is a legacy card.
