2-5
Introduction to
4100ES-S1 Cabinet
,
Continued
The CPU car
d LEDs indicate Bootloader status as shown in
Tabl
e
2-1.
Table 2-1. CPU Ca
rd LEDs 1 through 4
Status
Condition
LED D
LED C
LED B
LED A
Bootloader
Initialization
On (0.25s),
Off (0.25s)
On (0.25s),
Off (0.25s)
On (0.25s),
Off (0.25s)
On (0.25s),
Off (0.25s)
Bad Master
CRC or No
Master Present
On
Off
Of
f
Off
Diagnostic Fail
–
RAM
On
Off
Off
On
Diagnostic Fail
–
Bootloader CRC
On
Off
On
Off
Downloading
Master
On
Off
On
On
Downloading
CFIG
On
On
Off
Off
Downloading
MsgLib
On
On
Off
On
Downloading
BootLoader
On
On
On
Off
Download
Successful
On
On
On
On
Continued on n
ext page
CPU Card LEDs
24
26
