Simplex 4100ES-S1 User Manual

1-3
4100ES-S1 Part Codes
This section lists the parts that are supported by the 4100ES-S1 Fire Alarm System.
The following is a list of assemblies, cards and modules used in 4100ES-S1:
These parts are included in the base 4100ES-S1:
 742-516 CPU Motherboard (566-227)
 4100-7158 CPU Card (566-719)
 4100-9848AU System Power Supply, Australian version
 4100-6033 Alarm Relay Card (566-058) plugged onto the SPS and used
to supply the Brigade I/F relays.
 PA0915 Fuse Distribution Board, connected to the Auxiliary Power
terminals of the System Power Supply
 4100-2300 Expansion Bay Assembly (includes the metalwork with the
PDI back-plane)
 4100-1288 64 LED/64 Switch Controller module with mounting plate
 4100-1282 8 SW/16 LED red/yellow module (2 off)
These parts may be used to expand a 4100ES-S1:
 4100-1282 8 SW/16 LED red/yellow module
 4100-3101AU IDNET Module – 250 point capacity
 4100-3107AU IDNet+ Module – 246 point capacity, four loops
 4100-3204 4 Point Relay Module
 4100-3206 8 Point Relay Module
 4100-1289 64 LED/64 Switch Controller module
 4100-1287 24 Switch/24 red LED module
 4100-1284 8 Switch 16 red/green LED module
 4100-1281 8 Switch 8 yellow LED module
 4100-0160 Internet Interface Module (566-355).
 ME0456 Fan Control Module
The following kits are available to install in a base 4100ES-S1:
Brigade Interfaces
 FP0935 ASE Door Kit (ASE not included)
 FP0937 PPU/AIU Door Kit (PPU/AIU not included)
Other
 4100-KT0448 Fused DC Distribution Bd, XSPS AU Mounting
 4100-KT0468 4100 Motherboard to 4100U Bay, Mounting Kit
 4100-0766K T-GEN 50 and 4100U Mounting Bracket Kit
 ME0460 T-GEN 50 Evacuation Control Switch and Label
 ME0490 T-GEN 50/4100U Dynamic Microphone and lead
Continued on next page
Overview
Assemblies, Cards &
& Modules
Kits

Simplex 4100ES-S1 Specifications

General

Brand	Simplex
Model	4100ES-S1
Category	Control Panel
Language	English
