Glossary
AZF Alarm Zone Facility means of grouping multiple detectors or devices,
and providing common indication and control.
Class A Wiring Method of connecting multiple devices or units in a loop. This requires
up to twice as much wire but means that a short or open circuit in any
one section will not prevent communication with every device.
Class B Wiring Connection of multiple devices sequentially, or with spurs, uses the
minimum amount of cable, but a single wiring fault can affect all
devices at once.
FIP Fire Indicator Panel usually abbreviated to “panel”.
GPO General Power Outlet mains power socket.
IDNet Individual Device Network latest generation of Simplex analogue
addressable devices and the 2-wire loop that connects them.
MAPNet Multi-Application Peripheral Network an earlier version of
addressable device communication superseded by IDNet. Some
MAPNet devices can be used on IDNet loops.
NAC Notification Appliance Circuit switched DC output, usually with
supervision for powering notification appliances and warning system
devices.
NIC Network Interface Card provides network communications between
multiple 4100/4100ES panels.
PDI Power Distribution Interface the backplane power distribution system
used in 4100ES.
PID Product Identification (part number).
RUI Remote Unit Interface 2-wire communications loop used to connect
4100/4100ES master panels with slave transponders.
SPS System Power Supply the main 4100ES power supply and battery
charger module. Also includes an IDNet loop port, three NAC outputs,
and the brigade relay card.
