Simplex 4100ES-S1 User Manual

4-2
SPS Specifications
Table 4-1 summarizes the specifications for the SPS.
Table 4-1. SPS Input and Output Specifications
AC Input Specifications
SPS in Basic 4100ES-
S1 (4100-9848AU)
240 VAC + 6% -10% @ 50 Hz
2 A Maximum
DC Output Specifications
Voltage
Nominal 28VDC
Minimum: 19.5 VDC Maximum: 32 VDC
Ripple: 2 VDC p-p @ full load (9A)
Total Current (max)
24V Card
24V Aux
Each NAC (total A+B)
9A alarm load. Includes: NACs; +24V Card;
+24V Aux; SPS card including on-board IDNet.
5A non-alarm load. Includes the above
allowances, and allows for battery charging at
high rate.
2A max. See note.
2A max
3A max alarm load
2A max non-alarm load (when used as AUX
24V power).
SPS IDNet Output
30 V or 35 V (see note below)
Battery Charger Specifications
Input Voltage Range
21-33 VDC
Output Float Voltage
27.3 VDC 200 mV @ 20C, temperature
compensated at approximately -36mV/C
(0 C to 50 C)
Supervision Voltages
(nominal at 20C)
Charger High 28.4Vdc
Charger Low 26.2Vdc
Battery Low 24.3Vdc
Battery Depleted 19.4Vdc
Output Current Limit
1.4 A (For 6.2 – 18 Ah battery)
3.3 A (Default; for 18-110 Ah battery)
Notes:
 AC power must be provided to the 4100ES-S1 from a dedicated AC branch circuit.
The AC input is supervised wiring.
 The AC branch is terminated in the cabinet in the general power output (GPO)
mounted in the expansion bay. The SPS plugs into the GPO via a 3-pin plug and
mains lead.
 A mains fail fault is generated when the DC voltage drops below 20.3V (nominally at
mains voltage 204VAC).
Continued on next page
Input/Output/Battery
Specifications
