2-3
The Sur-Guard System III and the Bosch D6600 DACR support the following
protocol formats in the IMS:
• Ademco CID
• 3/1*
• 4-2*
• BFSK
• SIA Level 1
The IMS does not support the B32 Header option for the TCP/IP messages. The
TCP/IP for the Sur-Guard III works with the configured IMS default settings.
The IMS is able to receive messages from the Bosch D6600 DACR.
The following ratings apply to selected system hardware:
Order Number
(Reference Only)
Equipment
Watts
(maximum)
4190-7005 or -7006 Computer 240
4190-7122 17” LCD Monitor 72
4190-7123 19” LCD Monitor 96
4190-7222 17” LCD Monitor w/TS 72
4190-7223 19” LCD Monitor w/TS 96
4190-7224
19” LCD Monitor w/TS Rack
Mount
96
4190-9013 Printer 240
* Protocols are only available for security applications and signaling.
System Requirements, Continued
Sur-Guard System III
DACR/IMS Limitations
(Continued)
Electrical Input Ratings
