Simplex 4190 User Manual

6-9
For 4190-8103 IMS systems with the terminal block mounted to the PC chassis,
verify the information listed in Table 6-11.
Table 6-11. IMS 4190-8103 Model with UL Card ⎯ Device
Connection Points for Outputs 1 and 2
Location Value Function
TB1-2 to TB1-4 Short (<1 ohm) Output #1 Relay
Normally Closed
TB1-8 to TB1-10 Short (<1 ohm) Output #2 Relay
Normally Closed
TB1-4 to TB1-6 Open Circuit Output #1 Relay
Normally Open
TB1-10 to TB1-12 Open Circuit Output #2 Relay
Normally Open
Installing Cards and Jumpers, Continued
Continuity Check for Model
4190-8103 with UL Card
Installed
