5-10
1. After connecting the DACR(s) to the IMS, turn the power ON.
2. Press ENTER to bring up the login screen.
3. Enter CAFÉ as the access code screen.
4. Select the desired menu item:
• System Functions: To change Date and Time
• Line Card Programming: To program the line card
• CPM Options
Set com settings
07 – Baud Rate: 9600
08 – Data Bits: 8
09 – Parity: 0
Set heartbeat timer from 30 to 20
12 – heartbeat timer: 20
Set number of line cards
2E – number of line cards
1. After connecting the DACR(s) to the IMS, turn the power ON.
2. Press M/E to log on.
3. Enter 6600 and then M/E at access code screen.
4. Use the arrow keys to scroll and M/E to select the desired menu item:
• 2 CPU Configuration
2.2 Global
- 2.2.1 Time Setup
- 2.2.2 Date Setup
2.5 COM3 Automation Configuration
- 2.5.2 Baud Rate: 9600
- 2.5.3 Data Bit: 8
- 2.5.4 Parity: 0
- 2.5.5 Stop Bit: 1
- 2.5.6 Link Test: 30
Connecting DACRs to the IMS, Continued
Configuring System III DACR
Options
Configuring Bosch 6600
DACR Options
