Table 6-3 lists the jumper configurations for all RS-232 media cards.
Table 6-3. RS-232 Media Card ⎯ Jumper Positions
Jumper Function Position
Network Media Mother Board 1-2 (default)
P3
Service Port 2-3
Media Mother Board 1-2 (default)
P4
Network and Service Port 2-3
Supervised 1-2 (default)
P5
Unsupervised 2-3
Table 6-4 lists the jumper configurations for all wired media cards.
Table 6-4. Wired Media Card ⎯ Jumper Positions
Jumper Function Position
1 & 2
3 & 4
5 & 6
18 AWG (0.8231 mm
2
) Cable
7 & 8
P2
24 AWG (0.2047 mm
2
) Cable 3 & 4
There are no jumpers on the fiber optic media assembly.
Jumper Settings
RS-232 Media Card
(P/N 565-327)
Wired Media Card
(P/N 565-413)
Fiber Optic Media Assembly
