This section explains how to configure the UL Card (Model 4190-8103 IMS
only). Ensure that the switches are set on the UL card as listed in Tables 6-5 and
6-6.
Table 6-5. UL Card ⎯ Host Address I/O Selection Via SW1
Switch State
SW1-1 OFF
SW1-2 OFF
SW1-3 OFF
SW1-4 OFF
Table 6-6. UL Card ⎯ Configuration Via SW2
Switch No COM Ports
(No Daughter
Cards (Default)
SW2-1 OFF
SW2-2 OFF
SW2-3 OFF
SW2-4 OFF
SW2-5 OFF
SW2-6 OFF
SW2-7 OFF
SW2-8 OFF
Switch Settings
UL Card (P/N 565-283)
