Simplex 4190 User Manual

2-6
As you connect the equipment, refer to the figures below and the instructions
that follow.
Figure 2-2. Computer Rear Panel Layout – 2.8 Ghz or Faster
System using PCI 4190 Network Cards (Windows 2000
Platform)
Continued on next page
Connecting the IMS to the System, Continued
Connecting the Equipment
(Continued)
AC Power
Bracket for
4190-8103 only
Fan
Monitor
Sound
Card
QUAD 1
Serial Port
4190 Network
Card 3
USB
Video
Connector for
4190-8103 only
UL I/O Card
(If Used)
Mouse/
Keyboard
QUAD 2
Serial Port
4190 Network
Card 2
4190 Network
Card 4
4190 Network
Card 1
