0OWERSUPPLYCONNECTIONS
The internal voltage regulator will allow the CE32 MKII to operate nor-
mally over the power supply voltage range from 10 to 32 Vdc. Connec-
tion between the CE32 MKII and the external power supply ia
accomplished by means of the supplied power cable, which is approxi-
mately 1.5 meters long.
After connecting the cable to the power source, push the plug as far as it
will go into the receptacle marked PWR on the rear of the cabinet and
turn the plugs coupling ring clockwise until it makes a click.
4RANSDUCERCONNECTIONS
The installation should be carefully planned in advance, keeping in mind
the standard cable length of 10 meters (32feet) which will be connected
to the transducer. In the event where the standard cable is not long
enough, up to an additional 10 meters (32 feet) may be connected with-
out affecting the performance of the transducer. The cable must be of the
same type as the standard cable.
F 4HE#%-+))MUSTBETURNEDOFFWHILECONNECTINGDISCONNECTINGTHE
TRANSDUCERCABLE
The use of longer cable runs, while possible, always increases the likeli-
hood of increased interference and decreased performance. Care must be
taken when increasing the cable lengths to ensure that proper, adequate
and consistent shielding is maintained, that cable of adequate cross sec-
tion is used, and that all connections are properly made and protected
from the effects of the marine environment.
&USE
Warning! Using a fuse which is not specified for your equipment can
cause it to blow the instant the CE32 MKII has been switched on or it
will not protect the equipment in the event of trouble.
.-%!INTERFACECONNECTIONS
NMEA 0183 interface connections are made to the receptacle marked
NMEA on the rear of the cabinet.
F 4HE#%-+))MUSTBETURNEDOFFWHILECONNECTINGDISCONNECTINGTHE
INTERFACECABLE
#HAPTER #%-+)))NSTALLATIONANDSERVICE
96
