2%-/4%
Pin 1
TX A (DATA OUT)
Pin 2 TX B (RETURN)
Pin 3 RX A (DATA IN)
Pin 4 RX B (RETURN)
Pin 5 REMOTE DATA
Pin 6 CLK REMOTE
Ground screw
Fuse 2 AF
072
Pin 1 + 10-32 Vdc Brown
(Red)
Pin 2 - Battery Blue (Black)
.-%!
Pin 1
TX A (DATA OUT) White
Pin 2 TX B (RETURN) Brown
Pin 3 RX A (DATA IN) Yellow
Pin 4 RX B (RETURN) Green
Pin 5 ALARM/LOG Grey
Pin 6 MOB Pink
%#(/
Pin 1 SPEED LOG
Pin 2 5V SUPPLY SPEED LOG
Pin 3 DEPTH +
Pin 4 NC
Pin 5 DEPTH -
Pin 6 GND SHIELD
Pin 7 THERM.
!.4 Antenna
connection
%LECTRICALCONNECTIONS
%XTERNALLOGALARMRELAY
NMEA Relay 5V/50mA
0IN
5
2
%XTERNAL-/"SWITCHES
NMEA
0IN
6
2
Connectors,
seen from solder side
.-%!2%-/4%
%#(/
072
#%-+)))NSTALLATIONANDSERVICE #HAPTER
95
