,OAD 3PEEDDIAGRAM

S = Speed over ground.

V = Velocity towards

waypoint.

W = Speed through water.

S&D (Set and drift)*:

Speed and direction, true

or relative.

WIND*: Speed and direc-

tion.

#ONNECTIONTOEXTERNAL

SENSORSISREQUIRED

#ALL 3ETUPSPEEDDIAGRAM

The scale for the above

speed diagram can be ad-

justed in this display.

The time interval of the

speed diagram can be set

in 8 intervals from 1 min-

ute to 3 hours + freeze.

'OTOTHEFUNCTIONYOUWISHTOCHANGE

+EYINNEWFIGUREORCHANGESETTING

#ONFIRMENTRY

Setup speed diagram:

Scale for speed max: + 010kn

Scale for speed min: + 000kn

Speed over ground (S): ON

Velocity made good (V): ON

Water speed (W): ON

Time interval: 5 MIN.

3PEEDDIAGRAM

KEYSTOPRESS

3 *.*kn 6 *.*kn 7 *.*kn

[kn] 13:49 14:04 14:19

S&D:S *.* kn T***° R***° WIND:*.* ms ***°R

2,8MENU

ENT

0-9+/-

ENT
