Simrad NSO evo3S MPU User Manual

The autopilot controller for outboard motors
A Control bar
B Autopilot controller, disengaged
C Autopilot controller, engaged
D Mode indication
E Mode buttons
F Turns button
G Mode dependent buttons
H Standby button
When the autopilot controller is the active panel, it is outlined with a border.
Engaging and disengaging the autopilot
To engage the autopilot:
• Select the engage button to activate last active mode
• Select the mode button to display the list of available modes, then select the preferred
mode
The autopilot will engage in the selected mode, and the autopilot controller will change to
show active mode options.
To disengage the autopilot:
• Select the standby button
When the autopilot is in standby, the boat must be steered manually.
Autopilot indication
The status bar shows autopilot information as long as an autopilot computer is connected.
108
Outboard autopilot| NSO evo3S MPU Operator Manual

Simrad NSO evo3S MPU Specifications

General

Video Output	2 x HDMI
Connectivity	Wi-Fi, Bluetooth
Operating System	Linux
Ethernet Ports	2
USB Ports	2
Operating Voltage	12/24V DC
Power Supply	12/24V
